Superior beam quality due to Powell lens technology. This modular system in the standard dimensions will also meet your individual requirements.
1
Laser
Pseudo Random Pattern Projector for your 3D Machine Vision application. Available in the standard or compact dimensions.
The high power system with thermoelectric temperature stabilization for even better signal-to-noise ratios and DB-connector for monitoring/modulation.
Superior beam quality due to Powell lens technology. This modular system in compact dimensions will also meet your individual requirements.
L2S-TLP-Laser
Telecentric Laser Projector from Osela
This particular type of laser provides a telecentric laser line with a constant line length and width for your working range.
Therefore it is intended for high-precision surface inspections e.g. the smallest structures on electronic circuit boards.
The highest power system with thermoelectric temperature stabilization for even better signal-to-noise ratios and DB-connector for monitoring/modulation.
L2S-COS-Option
Option: Cosine Correction
Avoid too much reflected light in the middle of your sensor by using the cosine correction. The correction levels can be individually adjusted according your needs.
L2S-MF-Option
Option: Micron Focus
The micron focus option produces line thicknesses of a few micrometers.
The pulsed power laser in a small housing combines excellent beam quality, high power and minimal dimensions.
L2S-MC-Option
Option: Microcontroller
Monitor and control your single laser or even up to 32 at the same time with the microcontroller option.
The Line Laser Profiling System (LLPS) is a complete solution for analyzing line lasers up to 200 mm in length and down to 55 μm in width.
Diode laser with Gaussian beam profile. This modular system in the two different available dimensions will also meet your individual requirements.
Popular Products
This laser beam profiler features a CMOS sensor that guarantees frame rates of up to 60 Hz with high dynamics and is suitable for large beam diameters up to 11 mm.
The beam analysis camera WinCamD-IR-BB with integrated microbolometer array enables analyzes on long-wave lasers in the range of 2 μm to 16 μm.
This Laser Beam Profiler from DataRay is equipped with a CQD sensor and offers a spectral response in the SWIR range of 400 - 1700 nm with resolutions up to 1920 x 1080 pixel.
DataRay's ILM system is used for beam profile monitoring of high power lasers consisting of an attenuator for high powers, an imaging lens system and a camera system. The measurement of very small laser beams with diameters of less than micrometers is possible despite often high laser powers.
