FOV-Vorlauffaser-Ring
Pre and post fiber ring
Lead and lag fibers are used to adapt the meter to the target. The use of a launch fiber protects the adapters on the meter and evaluates the start or end events.
1
Fiber Optic Connectivity
FOV-Vorlauf-x-y-z
Leader fiber for OTDR measurements
Launch Fiber for OTDR applications in various lenght and connector assamblies are available.
