FLIR RS6780 MWIR Camera for Long-Range Imaging

search

Reference number: FLR-RS6780

The FLIR RS6780 scientific camera offers superior long-range thermal imaging with a unique combination of high-resolution detector, motorized filter wheel, and continuous zoom lens. Designed for challenging R&D applications, the RS6780 delivers exceptional measurement accuracy, advanced triggering options, and multiple software interfaces for streamlined data acquisition and analysis.

alt

Need more info?
Contact our expert.

Our Team

alt

Need more info?
Contact our expert.

Optical Test & Measurement Team
Phone: +49 8153 405-11

alt

Need more info?
Contact our expert.

Machine Vision Team
Phone: +49 8153 405-11

Description

FLIR RS6780: High-Precision Scientific MWIR Camera for Long-Range Imaging

The FLIR RS6780 redefines scientific long-range thermal imaging with its unmatched versatility and performance. This advanced MWIR camera empowers researchers to capture crisp, high-resolution thermal images of distant targets under demanding conditions.

Key Features:

Superior Measurement Accuracy:

  • 640 x 512 pixel resolution detector delivers detailed thermal data.
  • Continuous metric zoom lens (50-250 mm) maximizes target coverage (optional 3x afocal lens extends range to 750 mm).
  • Capture high-speed data at up to 125 Hz or over 4,000 Hz in subwindow mode.
  • Integrate neutral density filters for accurate imaging of high-temperature targets.
  • Customize cold filters for specific application needs.

Advanced Features for Flexibility:

  • Synchronize image capture with external events or instrumentation using TSPI-accurate timestamps.
  • Leverage advanced triggering for precise control over image capture.
  • Stream high-speed 14-bit data via Gigabit Ethernet and CoaXPress (CXP) interfaces.
  • Automatic filter recognition ensures correct filter application.

Multiple Software Interfaces:

  • Stream thermal data directly to Windows, macOS, or Linux computers.
  • Perform in-depth analysis with FLIR Research Studio's advanced tools.
  • Integrate camera functionality into third-party software using the FLIR Science Camera SDK.
  • Enable collaborative analysis of shared data with the free FLIR Research Studio Player.

Small, Rugged Form Factor:

  • IP65-rated enclosure withstands harsh outdoor environments.
  • Lightweight design simplifies integration.
  • In-house development of all camera components ensures seamless system operation.
  • Optional motorized lens cover provides additional protection.
