Reference number: FLK-FI-7000

Fluke Networks' CertiFiber Pro speeds up every step in the fiber certification process.

alt

Need more info?
Contact our expert.

Fiber Optics Team
Phone: +49 8153 405-11

Description

Overview

The CertiFiber® Pro Optical Attenuation Loss Test Kit improves the efficiency of fiber optics certification. The Taptive™ user interface simplifies setup, eliminates errors, and speeds diagnosis. A reference wizard ensures proper reference setting and eliminates errors due to negative attenuation values. CertiFiber Pro Optical Loss Testset (OLTS) builds on the pioneering Versiv platform and enables interconnect testing and reporting in Level 1 (Basic) / Level 2 (Extended) when paired with the OptiFiber Pro module. An accessible quad module supports singlemode and multimode and is multimode encircled flux compliant.Copper certificationand Wi-Fi analysis and Ethernet troubleshooting modules are also available. Analyze test results and create professional test reports using LinkWare management software.

The CertiFiber Pro Optical Loss test set's ability to test both ends of fiber lets you test the fiber connector end faces on both ends of your fiber link in under a second, so you can finish your job right the first time. With its automatic PASS/FAIL certification, the double-ended fiber optic testing capability eliminates the need for guesswork when checking fiber optics. This way, everyone becomes a fiber optic expert.

Product Highlights

  • Optical Loss Test Set with the fastest certification time: two fibers at two wavelengths in three seconds.
  • Encircled flux compliance to ANSI/TIA and ISO/IEC
  • Connected testing and reporting for Levels 1 (Basic) / 2 (Extended) when paired with OptiFiber® Pro OTDR.
  • The ProjX™ management system ensures proper and efficient execution of all tests.
  • Optical attenuation test set provides automatic pass/fail analysis according to industry standards or customer-specific test limits
  • Automatic PASS/FAIL certification of fiber optic connector end faces at both ends
  • Graphical indication of problem areas on end faces due to contamination, pits, chips and scratches
  • Modular Versiv™ design supports copper certification, fiber optic attenuation, OTDR testing, and fiber optic endface testing.
  • Taptive™ user interface provides simple, animated guidance to avoid errors due to incorrect reference settings and "negative attenuation" values.
  • Convenient quad modules support multimode and singlemode attenuation testing.
  • Extended singlemode range up to 130 km
  • Optical Loss Test Set with built-in Visual Fault Locator
  • Analyze test results and create professional test reports using LinkWare™ management software.
  • Compatible with LinkWare™ Live. Live Linkware allows easy tracking of job progress, real-time access to test results to quickly troubleshoot problems in the field, and easy transfer and consolidation of test results from the test set to LinkWare™ PC Cable Test Management Software.

Available CertiFiber Pro models:

  • CFP2-100-Q: The QUAD variant for multi- and single-mode Tier 1 certification.
  • CFP2-100-QI: The QUAD variant for multi- and singlemode Tier 1 certification incl. fiber inspection according to IEC 61300-3-35
  • Different KITS consisting of copper and fiber certification in one package
