Prism Based 2 Sensor Line Scan Camera

search

Reference number: BLV-BVCxxxx

Line-scan camera with 2 sensors for industrial applications for SWIR or polarized requirements, up to 4096 Pixel resolution, InGaAs and CMOS technology.

alt

Need more info?
Contact our expert.

Machine Vision Team

alt

Need more info?
Contact our expert.

Machine Vision Team
Phone: +49 8153 405-11

Description

2 sensor industrial line-scan camera for SWIR or polarized requirements up to 1600 nm.

Special prism technology providing best image quality and image separation.

Robust design ideal for industrial applications.

  • InGaAs and CMOS sensor technology
  • Resolution from 1024 up to 4096 pixel
  • Internal, pixel accurate sensor synchronisation for easy usage
  • Multiple interface: CameraLink
  • SDK available

Find suitable lenses for your application from us.

All camera models can be adapted to the requirements of your application. Contact us for consultancy.

Type No. Sensors Technology Spectrum Resolution max. Frame Rate Optical Mount Interface Specials
BVC3220LM 2 InGaAs
InGaAs		 900 - 1290 nm
1290 - 1600 nm		 1024 pixels 40 kHz M52 CameraLink
BVC3320LM 2 B/W CMOS
B/W CMOS		 400 - 700 nm 2048 pixels 64.308 kHz M52 CameraLink 2 Polarizing filters P- and S-wave
BVC3340LM 2 B/W CMOS
B/W CMOS		 400 - 700 nm 4096 pixels 34.602 kHz M52 CameraLink 2 Polarizing filters P- and S-wave
