SCT-350D Set of Chopping Discs

search

Reference number: SCT-350D

1 set: One each of 2, 4, 10 and 40 slot 30 mm discs. (20 and 80 slot discs are also available)

alt

Need more info?
Contact our expert.

Optics & Optomechanics Team
Phone: +49 8153 405-11

Description

SCT-350D Set of Chopping Discs

  • Disc types: 2, 4, 10 and 40 slot (20 and 80 slot discs are also available)
  • Material: Half hard brass, 0.25 mm thick
  • Diameter: 30 mm
  • Surface Finish: Chemically blacked
  • Mark to Space Ratio: 1 to 1

Frequency Range

Disc

Frequency (Hz)

Aperture

Phase Jitter, Max

r

a

b

d

SCT-350D2

(2 slots)

10 – 500

9.0

23.6

9.4

9.0

TBA

SCT-350D4

(4 slots)

20 – 1000

9.0

11.8

4.7

8.3

TBA

SCT-350D10

(10 slots)

50 – 2500

8.0

4.4

1.9

3.7

TBA

SCT-350D20

(20 slots)

100 – 5000

8.0

2.2

0.94

2.0

TBA

SCT-350D40

(40 slots)

200 – 10000

8.0

1.1

0.47

1.0

TBA

SCT-350D80

(80 slots)

400 - 20000

5.0

0.55

0.35

0.5

TBA
