Part number: OSE-TFA-1015R03-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 90
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 10×15
Thickness of the optic [mm]: 3
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1015R03-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 10×15
Thickness of the optic [mm]: 3
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1015R05-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 10×15
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1015R05-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 10×15
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1525R03-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 15×25
Thickness of the optic [mm]: 3
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1525R03-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 15×25
Thickness of the optic [mm]: 3
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1525R05-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 15×25
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-1525R05-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 15×25
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2030R05-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 20×30
Thickness of the optic [mm]: 6
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2030R05-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 20×30
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2030R05-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 20×30
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2535R05-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 25×35
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2535R05-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 25×35
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-2535R05-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 25×35
Thickness of the optic [mm]: 5
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-3040R06-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 30×40
Thickness of the optic [mm]: 6
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-3040R06-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 30×40
Thickness of the optic [mm]: 6
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-3040R06-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 30×40
Thickness of the optic [mm]: 6
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-4050R08-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 40×50
Thickness of the optic [mm]: 8
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-4050R08-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 40×50
Thickness of the optic [mm]: 8
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-4050R08-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 40×50
Thickness of the optic [mm]: 8
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-5060R10-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 50×60
Thickness of the optic [mm]: 10
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-5060R10-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 50×60
Thickness of the optic [mm]: 10
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-5060R10-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 50×60
Thickness of the optic [mm]: 10
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-6080R12-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 60×80
Thickness of the optic [mm]: 12
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-6080R12-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 60×80
Thickness of the optic [mm]: 12
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-6080R12-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 60×80
Thickness of the optic [mm]: 12
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-80100R15-1
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 80×100
Thickness of the optic [mm]: 15
Curvature [mm]: ∞
Material: BK7
Flatness: λ/1
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-80100R15-4
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 80×100
Thickness of the optic [mm]: 15
Curvature [mm]: ∞
Material: BK7
Flatness: λ/4
Surface Quality (Scratch-Dig): 40-20
Part number: OSE-TFA-80100R15-10
Type: Aluminium Mirror (Rectangle)
Wavelength range [nm]: 300 - 1200
Angle of incidence [°]: 0-45
Reflectivity [%]: 92
Coating: Al+MgF2
Laser Damage Threshold (J/cm²): 0.25
Diameter [mm]: 80×100
Thickness of the optic [mm]: 15
Curvature [mm]: ∞
Material: BK7
Flatness: λ/10
Surface Quality (Scratch-Dig): 40-20
