Reference number: GEE-GEVXD

Multispectrale LED

alt

Need more info?
Contact our expert.

Machine Vision Team
Phone: +49 8153 405-11

Description

MULTISPECTRAL LED BAR

Useful in all prototypes or machinery where it is necessary to understand which is the most suitable lighting for a specific object with a single illuminator.
Useful in all production machines that analyze different products on a single line, as with a single illuminator it is possible to have up to 12 different wavelengths.
Useful in analysis laboratories where it is necessary to highlight material samples using particular wavelengths.

GEVXD LINEAR LIGHT SWIR

Illuminators for linear or matrix cameras with SWIR wavelength from 980 to 1650 nm.
From 1 to 4 independent power LED channels in a single lamp Length from 20 to 600 cm, Standard model IP54, Custom model IP65.


Profile Length [cm]

Boards N.

Wavelength [nm]

Standard current supply @ 24 V [A]

Power consumption [W]

Number of LEDs

Range

GEVXD28-MS-400-1650

28

1

400 - 1650

2.0

50 W

12 x 6

VIS + NIR + SWIR

GEVXD108-MS-400-1650

108

4

400 - 1650

8.0

200 W

12 x 24

VIS + NIR + SWIR

GEVXD214-MS-400-1650

180

8

400 - 1650

16.0

380 W

12 x 48

VIS + NIR + SWIR

GEVXD28-MS-365-980

28

1

365 - 980

1.5

35 W

12 x 6

UVA + VIS + NIR

GEVXD55-MS-365-980

55

2

365 - 980

3.0

70 W

12 x 12

UVA + VIS + NIR

GEVXD161-MS-365-980

161

6

365 - 980

12.0

280 W

12 x 36

UVA + VIS + NIR
