NUV Objective Lenses

Reference number: OSE-PAL-20-NUV-LC07-A

With its long working infinity correction function, this objective can be used for a laser system and coaxial observation. It is also used for near UV light observation.

Item Name

Magnification

Need more info?
Contact our expert.

Our Team

Description

NUV Objective Lenses

Those products may also interest you

High resolution microscope OptoNano 200

OSE-PT-ON200

€0.00
F-Theta Lenses

OSE-f-Theta

€4,284.40
F-Theta Lenses for YAG

OSE-f-Theta-YAG

€685.50
F-Theta Lenses for CO2 Laser

OSE-f-Theta-10600

€1,037.10
Tube Lens: Wavelengths from fundamental to 3rd...

OSE-TL-Y3

€857.10

Magnification: 20
Wavelength Range [nm]: 355 / 532
Focal length f [mm]: 10
Focal depth [µm]: ± 1,7
Numerical aperture (NA): 0.4
Working distance (WD) [mm]: 17.25
Resolution [µm]: 0.69
Weight [kg]: 0.35

Magnification: 50
Wavelength Range [nm]: 355 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 1,4
Numerical aperture (NA): 0.45
Working distance (WD) [mm]: 15.1
Resolution [µm]: 0.61
Weight [kg]: 0.36

Magnification: 100
Wavelength Range [nm]: 355 / 532
Focal length f [mm]: 2
Focal depth [µm]: ± 0,8
Numerical aperture (NA): 0.57
Working distance (WD) [mm]: 11.23
Resolution [µm]: 0.48
Weight [kg]: 0.51

Magnification: 50
Wavelength Range [nm]: 355 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 0,65
Numerical aperture (NA): 0.65
Working distance (WD) [mm]: 10
Resolution [µm]: 0.42
Weight [kg]: 0.38

Magnification: 100
Wavelength Range [nm]: 355 / 532
Focal length f [mm]: 2
Focal depth [µm]: ± 0,6
Numerical aperture (NA): 0.7
Working distance (WD) [mm]: 10
Resolution [µm]: 0.39
Weight [kg]: 0.53

Magnification: 50
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 1,4
Numerical aperture (NA): 0.45
Working distance (WD) [mm]: 15,05
Resolution [µm]: 0.61
Weight [kg]: 0.36

Magnification: 100
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 2
Focal depth [µm]: ± 0,8
Numerical aperture (NA): 0.57
Working distance (WD) [mm]: 11,17
Resolution [µm]: 0.48
Weight [kg]: 0.39

Magnification: 20
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 10
Focal depth [µm]: ± 1,7
Numerical aperture (NA): 0.4
Working distance (WD) [mm]: 17,4
Resolution [µm]: 0.69
Weight [kg]: 0.35

Magnification: 50
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 1,4
Numerical aperture (NA): 0.45
Working distance (WD) [mm]: 15,01
Resolution [µm]: 0.61
Weight [kg]: 0.36

Magnification: 100
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 2
Focal depth [µm]: ± 0,8
Numerical aperture (NA): 0.57
Working distance (WD) [mm]: 11,13
Resolution [µm]: 0.48
Weight [kg]: 0.39

Magnification: 50
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 0,7
Numerical aperture (NA): 0.65
Working distance (WD) [mm]: 9,91
Resolution [µm]: 0.42
Weight [kg]: 0.51

Magnification: 50
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 4
Focal depth [µm]: ± 0,7
Numerical aperture (NA): 0.65
Working distance (WD) [mm]: 9,89
Resolution [µm]: 0.42
Weight [kg]: 0.51

Magnification: 20
Wavelength Range [nm]: 360 / 532
Focal length f [mm]: 10
Focal depth [µm]: ± 1,7
Numerical aperture (NA): 0.4
Working distance (WD) [mm]: 17,35
Resolution [µm]: 0.69
Weight [kg]: 0.35
