Optics & Optomechanics
Manual Positioning Systems
OSE-KSPS: Vacuum, Diameter40 mm

OSE-KSPS: Vacuum, Diameter40 mm

Reference number: OSE-KSPS-406M

Table Size in mm

Table Size in mm

Need more info?
Contact our expert.

Our Team

I am interested in:

an offer

information material

a call and advice

*Required field

reCAPTCHA

Write your question

Email address^*

Message^*

^* Required fields

Question sent

Your question has been sent!

Your question cannot be sent!

Description

Type: Vacuum
Tabel Size [mm]: ?40
Rotation Range [°]: Coars: 360° Fine: ±5°
Scale Readable Resolution: 2°
Micrometer Position: Center
Micrometer Readable Resolution [mm]: 1´24.2´´
Bearing type: Lapping method
Primary Material: Stainless steel
Finish: None
Load Capacity [N]: 49
Max. Moment Capacity / Pitch [Nm]: 0.3
Moment Stiffness / Pitch [´´/Ncm]: 1.5
Parallelism [µm]: 30
Eccentricity [µm]: 20
Wobble [µm]: 20
Gewicht in kg: 0.3

Downloads

OSE-KSPS.pdf

OSE-KSPS-406M_STP.zip

ManualStages.zip

Actuators.pdf

Type: Vacuum
Tabel Size [mm]: ?60
Rotation Range [°]: Coars: 360° Fine: ±5°
Scale Readable Resolution: 1°
Micrometer Position: Side
Micrometer Readable Resolution [mm]: 55.8´´
Bearing type: Lapping method
Primary Material: Stainless steel
Finish: None
Load Capacity [N]: 68.6
Max. Moment Capacity / Pitch [Nm]: 0.75
Moment Stiffness / Pitch [´´/Ncm]: 1
Parallelism [µm]: 50
Eccentricity [µm]: 20
Wobble [µm]: 20
Gewicht in kg: 0.6

Downloads

OSE-KSW.pdf

OSE-KSPS-606M_STP.zip

ManualStages.zip

Actuators.pdf
