Quick Finder for Laser Adjustment Goggles
Reference number: L2K-LJQF
Quick-Finder for laser adjustment glasses
Need more info?
Contact our expert.
Our Team
Description
From the following table you can select a required laser adjustment goggle for the most common laser wavelengths and laser powers.
The table is valid for cw lasers only.
If you have a pulsed laser or if you need more extensive selection criteria, you can use our free of charge Laser Safety Goggles finder.
Please note that for determining of the proper protection value the complete optical setup must be taken into account including any lenses, mirrors, reflections, etc.. Therefore, please check with your laser safety officer on site the required protection value.
Laser Adjustment Goggles according to DIN EN 208:
| Wavelength in nm | CW Power up to 10 mW | CW Power up to 100 mW | CW Power up to 1 W | CW Power up to 10 W |
| 405 | NIR-RBA-38 | - | - | - |
| 445 | UNV-P1019-562 | NIR-ABL-38 | - | - |
| 473 | - | - | UNV-P1032-562 | |
| 488 | - | NIR-AL3-38 | ||
| 514 | - | UNV-P1019-562 | ||
| 532 | UNV-P1019-562 | UNV-P1025-5X7 | NIR-AG3-38 | |
| 561 | - | NIR-ZSA-38 | - | |
| 589 | - | UNV-P1031-562 | - | - |
| 593 | UNV-P1018-562 | - | - | |
| 633 | NIR-RA2-38 | UNV-P1022-5X7 | NIR-RA3-38 | |
| 640 | UNV-P1031-562 | NIR-RA2-38 | ||
| 655 | NIR-RA2-38 | UNV-P1022-5X7 | ||
| 660 | NIR-RA3-38 | - | ||
| 671 | UNV-P1031-562 | - | - | |
| 690 | - | - |
All information without guarantee.
