Reference number: CHY-C-1040
The C-1040 is a fixed wavelength femtosecond laser source that delivers ultrashort pulses with high average powers in the near-IR.
Need more info?
Contact our expert.
Our Team
Description
The C-1040 is the next generation in femtosecond laser systems, which no longer need hours in set up time. The light emitted from the C-1040 originates from a single mode fiber, ensuring superior beam quality. Our laser source does not require water cooling and comes with a simple user interface, making it one of the easiest laser sources to operate.
Applications
SHG and multi-photon microscopy
Light sheet microscopy
Optogenetics imaging experiments
Pump source for non-linear optics (OPOs, SHG)
THz generation
Supercontinuum generation
Time resolved experiments (e.g. TCSPC/FLIM)
Technical Data
Specifications 1040 Low Power
Output power Up to 500 mW
Wavelength 1030 nm
Pulse duration < 150 fs
Pulse energy 5 nJ
Pulse repetition frequency 100 MHz
Control interface Web browser interface. Ethernet & serial port (RS232) also available.
Cooling Air-cooled
Specifications 1040 Mid Power
Output power 2.5 W
Wavelength 1040 nm
Pulse duration < 150 fs
Pulse energy 25 nJ
Pulse repetition frequency 100 MHz
Control interface Web browser interface. Ethernet & serial port (RS232) also available.
Cooling Air-cooled
Specifications 1040 High Power
Output power > 3.5 W
Wavelength 1040 nm
Pulse duration < 150 fs
Pulse energy > 35 nJ
Pulse repetition frequency 100 MHz
Control interface Web browser interface. Ethernet & serial port (RS232) also available.
Cooling Air-cooled
Dimensions
Length 426 mm
Width 250mm
Height 70 mm
Power Supply
19” 2U rack mount unit
