Laser light module
Reference number: SOL-920-00001
Fiber-coupled white laser light module.
Need more info?
Contact our expert.
Our Team
Description
White laser light module
The LaserLight fiber module from SLD Laser is the world's first high-luminance, white-illuminated laser light module.
The module provides safe, high-efficiency fiber transmission of light from a blue laser diode to a phosphor module emitting 500 lumens and more than 1000 Mcd / m² as incoherent wide-spectrum white light.
The possible fields of application include:
- Entertainment
- Architecture
- Outdoor
- remote lighting
Product features:
| Parameter | unit | Typical values |
| Luminous Output | lm | 500 |
| Light Emitting Region (dia.) | mm | 0.35 |
| Luminous Intensity (peak) | cd | 200 |
| Viewing Angle | deg | 120 |
| Color Temperature (CCT) | K | 6500 |
| Color Rendering Indes | CRI | 65 |
| Forward Current | A | 2.7 |
| Forward Voltage | V | 4.8 |
| Package Dim. (Source) | mm | 32 x 29 |
| Package Dim. (Laser) | mm | 55 x 54 |
