Optics & Optomechanics
Filters
UV Filters, OSE-NHOTM

UV Filters, OSE-NHOTM

Reference number: OSE-NHOTM-25.4C3.3

Dichroic filter transmit only visible light and reject ultraviolet and infrared light.

Diameter / Length in mm

Shape

Need more info?
Contact our expert.

Our Team

I am interested in:

an offer

information material

a call and advice

*Required field

reCAPTCHA

Write your question

Email address^*

Message^*

^* Required fields

Question sent

Your question has been sent!

Your question cannot be sent!

Description

Those products may also interest you

Continuously Variable Filters

DOT-Variable-Filters

€0.00
Absorptive Neutral Density Filter, Circle

OSE-AND-C

€24.40
Absorptive Neutral Density Filter, Mounted

OSE-MAN

€40.80
Absorptive Neutral Density Filter, Square

OSE-AND-S

€24.40
Absorptive Neutral Density Filter, YAG, Circle

OSE-ANDY-C

€44.90

Surface Quality: 80-50

Diameter ØD [mm]: Ø25.4

Material: BK7

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.3

Transmittance (420 - 680nm): >Average 85

Transmittance (200 - 380nm):

Transmittance (730 - 1500nm):

Incident angle: 0°-15°

Downloads

OSE-nhotm.pdf

Surface Quality: 80-50

Diameter ØD [mm]: Ø50.8

Material: BK7

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.3

Transmittance (420 - 680nm): >Average 85

Transmittance (200 - 380nm):

Transmittance (730 - 1500nm):

Incident angle: 0°-15°

Downloads

OSE-nhotm.pdf

Surface Quality: 80-50

Length A [mm]: 25.4

Material: BK7

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.3

Transmittance (420 - 680nm): >Average 85

Transmittance (200 - 380nm):

Transmittance (730 - 1500nm):

Incident angle: 0°-15°

Downloads

OSE-nhotm.pdf

Surface Quality: 80-50

Length A [mm]: 50.8

Material: BK7

Coating: Dielectric multi-layer coating

Thickness t [mm]: 3.3

Transmittance (420 - 680nm): >Average 85

Transmittance (200 - 380nm):

Transmittance (730 - 1500nm):

Incident angle: 0°-15°

Downloads

OSE-nhotm.pdf

Dichroic filter transmit only visible light and reject ultraviolet and infrared light.
