Optics & Optomechanics
Filters
IR Filters

IR Filters

Reference number: OSE-ITF-50S-76IR

A filter that transmits IR wavelengths and absorbs the UV and Visible range.

Transition wavelength in nm

Need more info?
Contact our expert.

Our Team

I am interested in:

an offer

information material

a call and advice

*Required field

reCAPTCHA

Write your question

Email address^*

Message^*

^* Required fields

Question sent

Your question has been sent!

Your question cannot be sent!

Description

Those products may also interest you

Continuously Variable Filters

DOT-Variable-Filters

€0.00
Absorptive Neutral Density Filter, Circle

OSE-AND-C

€24.40
Absorptive Neutral Density Filter, Mounted

OSE-MAN

€40.80
Absorptive Neutral Density Filter, Square

OSE-AND-S

€24.40
Absorptive Neutral Density Filter, YAG, Circle

OSE-ANDY-C

€44.90

Transition wavelength ?T [nm]: 760±10

Transition Interval ? [nm]: <60

Color tone: Black

Downloads

OSE-itf.pdf

ITF-76IR.xls

Transition wavelength ?T [nm]: 800±10

Transition Interval ? [nm]: <60

Color tone: Black

Downloads

OSE-itf.pdf

ITF-80IR.xls

Transition wavelength ?T [nm]: 830±10

Transition Interval ? [nm]: <60

Color tone: Black

Downloads

OSE-itf.pdf

ITF-83IR.xls

Transition wavelength ?T [nm]: 730±10

Transition Interval ? [nm]: <40

Color tone: Black

Center wavelength [nm]: 790±10

Transmittance for center wavelength [%]: 85±3

Absorption limit short wavelength [%]: 691

Transmittance at short absorption limit [%]: <0.1

Absorption limit long wavelength [nm]: 1225

Transmittance at long absorption limit [%]: <0.2

Downloads

OSE-itf.pdf

ITF-83RT.xls

A filter that transmits IR wavelengths and absorbs the UV and Visible range.
