Cold Mirrors

Reference number: OSE-CLDM-25.4S3.3

The principle of the cold mirror is reflecting the visible range light and leave the UV range light to transmit.

Need more info?
Contact our expert.

Our Team

Description

Surface Quality: 80-50

Length A [mm]: 25.4±0.5

Material: B270 or BK7

Wavelength Range [nm]: 400-2000

High transmittance range (45 degrees incident) [nm]: 800- 2000

Transmittance (45 degrees incident) [%]: >75

Cutoff range (45 degrees incident) [nm]: 420- 700

Transmittance of cutoff range (45 degrees incident) [%]: >95

Wavelength at 50% [nm]: 760±10

Thickness t [mm]: 3.3±0.3

Incident angle: 45°

Downloads

OSE-cldm.pdf

DOWNLOAD

CLDM-T45.xls

DOWNLOAD

Surface Quality: 80-50

Length A [mm]: 50.8±0.5

Material: B270 or BK7

Wavelength Range [nm]: 400-2000

High transmittance range (45 degrees incident) [nm]: 800- 2000

Transmittance (45 degrees incident) [%]: >75

Cutoff range (45 degrees incident) [nm]: 420- 700

Transmittance of cutoff range (45 degrees incident) [%]: >95

Wavelength at 50% [nm]: 760±10

Thickness t [mm]: 3.3±0.3

Incident angle: 45°

Downloads

OSE-cldm.pdf

DOWNLOAD

CLDM-T45.xls

DOWNLOAD

Surface Quality: 60-40

Length A [mm]: 50.0±0.3

Material: B270 or BK7

Wavelength Range [nm]: 400-2000

High transmittance range (45 degrees incident) [nm]: 800- 2000

Transmittance (45 degrees incident) [%]: >80

Cutoff range (45 degrees incident) [nm]: 400- 700

Transmittance of cutoff range (45 degrees incident) [%]: >90

Wavelength at 50% [nm]: 760±10

Thickness t [mm]: 1.0±0.1

Incident angle: 45°

Downloads

OSE-cldm.pdf

DOWNLOAD

CLDM-T45.xls

DOWNLOAD

Surface Quality: 80-50

Diameter ØD [mm]: Ø25.4±0.5

Material: B270 or BK7

Wavelength Range [nm]: 400-2000

High transmittance range (45 degrees incident) [nm]: 800- 2000

Transmittance (45 degrees incident) [%]: >75

Cutoff range (45 degrees incident) [nm]: 420- 700

Transmittance of cutoff range (45 degrees incident) [%]: >95

Wavelength at 50% [nm]: 760±10

Thickness t [mm]: 3.3±0.3

Incident angle: 45°

Downloads

OSE-cldm.pdf

DOWNLOAD

CLDM-T45.xls

DOWNLOAD

Surface Quality: 80-50

Diameter ØD [mm]: Ø50.8±0.5

Material: B270 or BK7

Wavelength Range [nm]: 400-2000

High transmittance range (45 degrees incident) [nm]: 800- 2000

Transmittance (45 degrees incident) [%]: >75

Cutoff range (45 degrees incident) [nm]: 420- 700

Transmittance of cutoff range (45 degrees incident) [%]: >95

Wavelength at 50% [nm]: 760±10

Thickness t [mm]: 3.3±0.3

Incident angle: 45°

Downloads

OSE-cldm.pdf

DOWNLOAD

CLDM-T45.xls

DOWNLOAD
