Objectifs endocentriques

This laser beam profiler features a CMOS sensor that guarantees frame rates of up to 60 Hz with high dynamics and is suitable for large beam diameters up to 11 mm.

The beam analysis camera WinCamD-IR-BB with integrated microbolometer array enables analyzes on long-wave lasers in the range of 2 µm to 16 µm.

This Laser Beam Profiler from DataRay is equipped with a CQD sensor and offers a spectral response in the SWIR range of 400 - 1700 nm with resolutions up to 1920 x 1080 pixel.

DataRay´s ILM system is used for beam profile monitoring of high power lasers consisting of an attenuator for high powers, an imaging lens system and a camera system. The measurement of very small laser beams with diameters of less than micrometers is possible despite often high laser powers.

A main feature of the WinCamD is the optional M2 Stage. Thus, it can be easily extended to a complete M2 measurement system.
