Laser blanc SMD
Reference number: SOL-910-00001
Source laser fibrée blanche
Besoin de plus d'informations ?
Contactez notre expert.
Notre équipe
Description
White laser light as SMD component
The SLD Laser Laser Diode is the world's first high brightness white illuminated laser diode.
The compact (7 mm) SMD component manages to produce a white light beam with 500 lumens and more than 1000 Mcd / m². This makes it possible to illuminate distant objects.
The possible fields of application include:
- Entertainment
- Architecture
- Outdoor
- remote lighting
Product Features
:
| Parameter | unit | Typically values |
| Luminous Output | lm | 500 |
| Light Emitting Region (dia.) | mm | 0.35 |
| Luminous Intensity (peak) | cd | 200 |
| Viewing Angle | deg | 120 |
| Color Temperature (CCT) | K | 6500 |
| Color Rendering Indes | CRI | 65 |
| Forward Current | A | 1.5 |
| Forward Voltage | V | 9 |
| Package Dim. | mm | 7.0 sq x 2.6 |
