Reference number: UNV-P1011-xxx

Laser safety goggles according to DIN EN 207 with polycarbonate filter and a daylight transmission of 2 %.

alt

Need more info?
Contact our expert.

Laser Safety Team

Description

Laser goggles (593-875 nm)

Lasers have found their way into many areas of industry, medicine and research. Accordingly, laser protection is essential for the safe handling of these intensive beam sources of different wavelength, power and radiation mode. The CE certification guarantees compliance with the valid standards according to international and European optical and laser standards (DIN EN 207 / EN208).

UNV-P1011-xxx (xxx=frame), Laser Safety Goggle according to DIN EN 207

Filter material: Polycarbonate
Filter color: Green*
Daylight transmission: 2 %
(*the picture shows one filter color as an example only)

Optical density:
See filter curve in the picture gallery

Protection values:
190-315 D LB7 + IR LB3
593-875 DIR LB3
610-865 DIR LB4
625-855 DIR LB5
635-850 D LB5 + IR LB6
645-840 D LB5 + IR LB7

Frame -561:
  • Smart design
  • Soft hypoallergenic nose pad
  • Adjustable temples
  • Ergonomic wraparound temples fit perfectly on user face

Frame -562:
  • Adjustable temples
  • Ergonomic wraparound temples fit perfectly on user face
  • Universal overspec on every prescription glasses


Frame -559G:
  • High power laser protection
  • High protection 2 mm aluminum shield
  • Adjustable elastic band improves the stability
  • Internal soft rubber eliminates local pressure
  • Can be worn over prescription glasses
