Semrock Tunable Bandpass Filter

Reference number: SEM-VersaChrome-TBP

The VersaChrome Tunable Bandpass Filter offer wavelength tunability over a very wide range of wavelengths by adjusting the angle of incidence with essentially no change in spectral performance.

Need more info?
Contact our expert.

Our Team

Need more info?
Contact our expert.

Optics & Optomechanics Team
Phone: +49 8153 405-11

Need more info?
Contact our expert.

Machine Vision Team
Phone: +49 8153 405-11

Description

Tunable Bandpass Filter VersaChrome

These game-changing optical filters do what no thin-film filter has ever done before: offer wavelength tunability over a very wide range of wavelengths by adjusting the angle of incidence with essentially no change in spectral performance. The tunable bandpass filter VersaChrome combines the highly desirable spectral characteristics and two-dimensional imaging capability of thin-film optical filters with the wavelength tuning flexibility of a diffraction grating. They are so innovative, they are patent pending.

With a tuning range of greater than 11 % of the normal-incidence wavelength (by varying the angle of incidence from 0 to 60°), only five filters are needed to cover the full visible spectrum. They are ideal for applications ranging from fluorescence imaging and measurements to hyperspectral imaging and high-throughput spectroscopy. With their excellent polarization insensitivity and high optical quality and damage threshold, they are well-suited for a wide range of laser applications as well.

Standard Overlap Tunable Bandpass Filters

At 60° CWL <	At 60° Average Transmission / Bandwidth	At 0° CWL >	At 0° Average Transmission / Bandwidth	Size (L x W x H)	Part Number Price
340.0	> 60% over 16 nm	378.0	> 80% over 16 nm	25.2 x 35.6 x 2.0 mm	TBP01-378/16-25x36
390.5	> 80% over 16 nm	438.0	> 90% over 16 nm	25.2 x 35.6 x 2.0 mm	TBP01-438/16-25x36
431.5	> 85% over 15 nm	487.5	> 90% over 15 nm	25.2 x 35.6 x 2.0 mm	TBP01-487/15-25x36
489.0	> 85% over 15 nm	547.0	> 90% over 15 nm	25.2 x 35.6 x 2.0 mm	TBP01-547/15-25x36
550.0	> 85% over 14 nm	617.0	> 90% over 14 nm	25.2 x 35.6 x 2.0 mm	TBP01-617/14-25x36
618.5	> 85% over 13 nm	697.0	> 90% over 13 nm	25.2 x 35.6 x 2.0 mm	TBP01-697/13-25x36
702.0	> 85% over 12 nm	796.0	> 90% over 12 nm	25.2 x 35.6 x 2.0 mm	TBP01-796/12-25x36

Extended Overlap Tunable Filters

At 60° CWL <	Average Transmission / Bandwidth	At 0° CWL >	Average Transmission / Bandwidth	Size (L x W x H)	Part Number
360.0	> 60% over 16 nm	400.0	> 85% over 16 nm	25.2 x 35.6 x 2.0 mm	TBP01-400/16-25x36
400.0	> 80% over 15 nm	448.0	> 90% over 15 nm	25.2 x 35.6 x 2.0 mm	TBP01-449/15-25x36
448.8	> 85% over 15 nm	501.5	> 90% over 15 nm	25.2 x 35.6 x 2.0 mm	TBP01-501/15-25x36
501.5	> 85% over 14 nm	561.0	> 90% over 14 nm	25.2 x 35.6 x 2.0 mm	TBP01-561/14-25x36
561.5	> 80% over 14 nm	627.7	> 90% over 14 nm	25.2 x 35.6 x 2.0 mm	TBP01-628/14-25x36
627.7	> 85% over 13 nm	703.8	> 90% over 13 nm	25.2 x 35.6 x 2.0 mm	TBP01-704/13-25x36
703.8	> 85% over 12 nm	790.0	> 90% over 12 nm	25.2 x 35.6 x 2.0 mm	TBP01-790/12-25x36
790.0	> 85% over 11 nm	900.0	> 90% over 11 nm	25.2 x 35.6 x 2.0 mm	TBP01-900/11-25x36
