Artikel-Nr.: SEI-DASISI-V2

Das DAISI-MT (Digital Automated Interferometer for Surface Inspection) ist ein Messgerät für die Endflächengeometrie von Multifaser-Steckverbindern, das auf dem gleichen Konzept wie die automatische Fokussierung und Kalibrierung von DAISI basiert.

alt

Für mehr Infos
Experten kontaktieren

Faseroptik Team

Beschreibung

The megapixel CCD used in this device achieves superior repeatability and reproducibility properties and rapid measuring speed. Moreover, because it is equipped with a USB 2.0 computer interface, like the DAISI it can be readily connected to a laptop computer.

Accuracy of Geometry Measurement
 *Repeatability/ReproducibilityRange
Curvature radius (mm) ±0.05% / ±0.05% 3 to flat
Spherical eccentricity (µm) ±0.5 / ±1 0 to 500
Fiber draw-in (nm) ±1 / ±1.5 ±160 (±15 000 white LED options)

?*Note: Repeatability and reproducibility
Repeatability refers to the numerical value that can be consistently observed in measurements repeated 50 times without the connector being disconnected and reconnected, while reproducibility refers to the numerical value that can be consistently observed in measurements repeated 50 times with the connector being disconnected and reconnected for each measurement, with the value observed being 1? in both cases.
